CAT-SENSORS-EU.BU.N.EN.2.2012.0.01.CC
21
Temperature
Sensors
Strap on/Contact
Temperature Sensors
STC100, 200, 500, 600
STC strap on temperature sensors are designed for surface pipe mounting.
The STC housing is equipped with a 20mm cable fitting.
Accuracy See Appendix A: Tables A, B, C, F
STC110, 510
The STC110 and 510 temperature sensors are designed for mounting on pipe
systems of max. Ø 100 mm. The temperature sensor is supplied with a connection
cable of 2m or 4m.
Accuracy See Appendix A: Tables A, C
STC120
STC120 is a temperature sensor designed for mounting on a pipe system of heating
coils Ø 10-15 mm. The sensor is supplied with a connection cable of 0.25m.
Accuracy See Appendix A: Table A
Part
number
Model
number
Description
System
5123202010 STC100
Contact Temperature
Sensor STC100
TAC Vista
TAC Xenta
5123206010 STC200
Contact Temperature
Sensor STC200
TAC I/NET
5123218010 STC500
Contact Temperature
Sensor STC500
Andover
Continuum
5126070000 STC600
Contact Temperature
Sensor STC600
Satchwell
5126020000 STC600D
Contact Temperature
Sensor STC600D
Drayton
Part
number
Model
number
Description
System
5123210000 STC110-200
Contact Temperature
Sensor STC110-200
TAC Vista
TAC Xenta
5123212000 STC110-400
Contact Temperature
Sensor STC110-400
TAC Vista
TAC Xenta
5123236000 STC210-200
Contact Temperature
Sensor STC210-200
TAC I/NET
5123238000 STC210-400
Contact Temperature
Sensor STC210-400
TAC I/NET
5123220000 STC510-200
Contact Temperature
Sensor STC510-200
Andover
Continuum
Part
number
Model
number
Description
System
5123214000 STC120
Contact Temperature
Sensor STC120
TAC Vista
TAC Xenta
