Humidity
Transmitters
SHR100
Living Space
Humidity Transmitter
SHR100
The SHR100 is an active sensor, which measures relative humidity (%RH) and
converts the measurement into two selectable output signals: voltage 0-10 V or
an electric current 4-20 mA.
The following options are available:
n
SHR100-T includes selectable temperature sensors NTC 1.8 kΩ and NTC 10 kΩ
for I/Net products.
n
SHR100-T5 includes selectable temperature sensors NTC 1.8 kΩ and NTC
10 kΩ for Continuum products.
n
SHR100-T6 includes temperature sensor NTC 5.02 kΩ for Satchwell products.
The transmitter consists of a sensor and amplifier, mounted together in a housing.
The SHR100 is mounted directly onto the wall or a backbox / J-box.
Specifications
Output
Selectable 4-20 mA, 0-10 V
Range
0-95% RH
Accuracy
±2%
Supply
24 Vac / 15-36 Vdc Power
Part
number
Model
number
Description
System
006902340 SHR100
Living Space Humidity
Sensor SHR100
All (%RH
only)
006902350 SHR100-T
Living Space Humidity +
Temperature SHR100-T
TAC I/NET
TAC Vista
TAC Xenta
006902390 SHR100-T5
Living Space Humidity +
Temperature SHR100-T5
Andover
Continuum
TAC Vista
TAC Xenta
006902420 SHR100-T6
Living Space Humidity +
Temperature SHR100-T6
Satchwell
