Temperature
Sensors
STO100, 200, 500, 600, 300
Outdoor Temperature
Sensors & Transmitters
STO100, 200, 500, 600
These outdoor sensors are intended for outdoor wall mounting. Variants are
available for TAC Vista, TAC I/NET, Andover Continuum and Satchwell systems. The
body has a 20mm conduit entry and the product is supplied with a conduit gland.
STO300
The STO300 transmitter is supplied as a complete unit, comprising a sensing
element and an amplifier mounted in a housing which is resistant to ultraviolet
light. The transmitter is intended for mounting on an outside wall, on the north side
where possible. The transmitter is connected over a 2-wire cable, which serves
both as power supply and signal transmission. The reading of the measured signal
is made over an external load resistance.
Specifications
Range
-40 to +90 °C
Accuracy
See Appendix A: Table A, C, F
Part
number
Model
number
Description
System
5141100010 STO100
Outdoor Temperature
Sensor STO100
TAC Vista
TAC Xenta
5123246000 STO200
Outdoor Temperature
Sensor STO200
TAC I/NET
5141104010 STO500
Outdoor Temperature
Sensor STO500
Andover
Continuum
5126060000 STO600
Outdoor Temperature
Sensor STO600
Satchwell
5126050000 SSO600
Outdoor Solar Temperature
Sensor SSO600
Satchwell
5126000000 STO600D
Outdoor Temperature
Sensor STO600D
Drayton
Part
number
Model
number
Description
System
006920501 STO300 -50/50
Outdoor Temperature
Sensor STO300
All
Specifications
Output
4-20 mA
Range
-50/+50 °C
Accuracy
±0.4 % of range
Supply
Min. 15Vdc, Max. 36Vdc
