Temperature
Sensors
STP660, 120, 620
Temperature Sensors
STP660
The STP660 temperature sensor is intended for immersion mounting in pipe
systems with a separate pocket (well), and has a telescopic probe extendable from
100mm to 300mm. This technology makes the product ideal for the HVAC service
industry as the probe is adjustable for any size pocket. The tip is primed with heat
conductive paste, ensuring that the time constant is optimised. The pocket is
sealed, making it easy to replace the sensor if necessary.
The STP housing is equipped with a 20mm cable fitting. A 20mm cable gland is
supplied. As there is a choice of both pocket material (brass or stainless steel) and
size (120mm or 200mm) for this sensor, the pocket must be ordered separately.
See the DWA range in the pocket / wells section of this catalogue.
Accuracy See Appendix A: Table F
STP120, 220, 620
The STP120, 220, 620 temperature sensors are intended for immersion mounting
in pipe systems without requiring a pocket (well). This product is for use in fast
time constant systems such as district heating applications. The STP housing is
equipped with a 20mm cable fitting. A 20mm cable gland is supplied.
Accuracy See Appendix A: Tables A, F
Part
number
Model
Number
Description
Probe
length
(mm)
System
5126080000 STP660
Pipe Temperature Sensor
STP660
100 to 300 Satchwell
Part
number
Model
Number
Description
Probe
length
(mm)
System
5123158010 STP120 –70
Pipe Temperature Sensor
STP120-70
70
TAC Vista
TAC Xenta
5123160010 STP120 –120
Pipe Temperature Sensor
STP120-120
120
TAC Vista
TAC Xenta
5123162010 STP120 –220
Pipe Temperature Sensor
STP120-220
220
TAC Vista
TAC Xenta
5123230000 STP220-70
Pipe Temperature Sensor
STP220-70
70
TAC I/NET
5123232000 STP220-120
Pipe Temperature Sensor
STP220-120
120
TAC I/NET
5123234000 STP220-220
Pipe Temperature Sensor
STP220-220
220
TAC I/NET
5126090000 STP620
Pipe Temperature Sensor
STP620
100
Satchwell
