Duct Temperature
Sensors
STD100, 200, 500
STD100, 200, 300
STD 100, 200 and 500 temperature sensors are intended for air duct mounting.
The STD housing is equipped with a Ø 20mm cut-out for the cable, a 20mm
conduit gland nut and a mounting flange.
Accuracy See Appendix A: Tables A, B, C
Part
number
Model
number
Description
Probe length (mm) System
5123002010 STD100-50 Duct Temperature Sensor STD100-50
50
TAC Vista, TAC Xenta
5123004010 STD100-100 Duct Temperature Sensor STD100-100
100
TAC Vista, TAC Xenta
5123006010 STD100-150 Duct Temperature Sensor STD100-150
150
TAC Vista, TAC Xenta
5123008010 STD100-200 Duct Temperature Sensor STD100-200
200
TAC Vista, TAC Xenta
5123010010 STD100-250 Duct Temperature Sensor STD100-250
250
TAC Vista, TAC Xenta
5123012010 STD100-300 Duct Temperature Sensor STD100-300
300
TAC Vista, TAC Xenta
5123014010 STD100-400 Duct Temperature Sensor STD100-400
400
TAC Vista, TAC Xenta
5123030010 STD200-50 Duct Temperature Sensor STD200-50
50
TAC I/NET
5123032010 STD200-100 Duct Temperature Sensor STD200-100
100
TAC I/NET
5123034010 STD200-150 Duct Temperature Sensor STD200-150
150
TAC I/NET
5123036010 STD200-200 Duct Temperature Sensor STD200-200
200
TAC I/NET
5123038010 STD200-250 Duct Temperature Sensor STD200-250
250
TAC I/NET
5123040010 STD200-300 Duct Temperature Sensor STD200-300
300
TAC I/NET
5123042010 STD200-400 Duct Temperature Sensor STD200-400
400
TAC I/NET
5123074010 STD500-150 Duct Temperature Sensor STD500-150
150
Andover Continuum
5123078010 STD500-250 Duct Temperature Sensor STD500-250
250
Andover Continuum
5123082010 STD500-400 Duct Temperature Sensor STD500-400
400
Andover Continuum
