Duct Temperature
Sensors
STD660, 670, 150, 550
Duct Temperature Sensors
STD660
The STD660 temperature sensor is intended for air duct mounting, and has a
telescopic probe extendable from 100mm to 300mm. The STD660 housing is
equipped with a Ø 20mm cut-out for the cable. A 20mm conduit gland nut and
a mounting flange are supplied with the product.
Accuracy See Appendix A: Table F
STD670
The STD670 temperature sensor is intended for air duct mounting.
The STD670 has a 1.5m fly-lead.
Accuracy See Appendix A: Table F
STD150, 550
The STD150 and 550 are intended for measuring air temperature in fan coil
applications or exhaust ducts.
The sensors, which are made of stainless steel, are delivered with a 2m (6.5 ft.)
cable, PVC sheathed overall. Mounting details such as screw and clamp are
included with the product.
Accuracy See Appendix A: Tables A, C
Part
number
Model
number Description
Probe
length (mm) System
5126030000 STD660 Duct Temperature
Sensor STD660
100 to 300 Satchwell
Part
number
Model
number
Description
System
5126040000 STD670
Duct Temperature Sensor
STD670
Satchwell
Part
number
Model
number
Description
System
5123058000 STD150
Duct Temperature Sensor
STD150
TAC Vista
TAC Xenta
5126058400 STD550
Duct Temperature Sensor
STD550
Andover
Continuum
