Temperature
Sensors
STP100, 200, 500
Immersion Temperature
Sensors for Pockets
STP100, 200, 500
These sensors are designed for immersion mounting in pipe systems with a separate
pocket (well). The pocket is sealed, making it easy to replace the sensor if necessary.
The STP housing is equipped with a 20mm cable fitting. A 20mm cable gland is
supplied. The pocket must be ordered separately.
Accuracy See Appendix A: Table A, B, C
Part
number
Model
number
Description
Probe
length
(mm)
System
5123102010 STP100-50
Pipe Temperature Sensor STP100-50
50
TAC Vista, TAC Xenta
5123104010 STP100-100
Pipe Temperature Sensor STP100-100
100
TAC Vista, TAC Xenta
5123106010 STP100-150
Pipe Temperature Sensor STP100-150
150
TAC Vista, TAC Xenta
5123108010 STP100-200
Pipe Temperature Sensor STP100-200
200
TAC Vista, TAC Xenta
5123110010 STP100-250
Pipe Temperature Sensor STP100-250
250
TAC Vista, TAC Xenta
5123112010 STP100-300
Pipe Temperature Sensor STP100-300
300
TAC Vista, TAC Xenta
5123114010 STP100-400
Pipe Temperature Sensor STP100-400
400
TAC Vista, TAC Xenta
5123130010 STP200-50
Pipe Temperature Sensor STP200-50
50
TAC I/NET
5123132010 STP200-100
Pipe Temperature Sensor STP200-100
100
TAC I/NET
5123134010 STP200-150
Pipe Temperature Sensor STP200-150
150
TAC I/NET
5123136010 STP200-200
Pipe Temperature Sensor STP200-200
200
TAC I/NET
5123138010 STP200-250
Pipe Temperature Sensor STP200-250
250
TAC I/NET
5123140010 STP200-300
Pipe Temperature Sensor STP200-300
300
TAC I/NET
5123142010 STP200-400
Pipe Temperature Sensor STP200-400
400
TAC I/NET
5123170010 STP500-50
Pipe Temperature Sensor STP500-50
50
Andover Continuum
5123172000 STP500-100
Pipe Temperature Sensor STP500-100
100
Andover Continuum
5123174010 STP500-150
Pipe Temperature Sensor STP500-150
150
Andover Continuum
5123176010 STP500-200
Pipe Temperature Sensor STP500-200
200
Andover Continuum
5123180010 STP500-300
Pipe Temperature Sensor STP500-300
300
Andover Continuum
5123182000 STP500-400
Pipe Temperature Sensor STP500-400
400
Andover Continuum
5126010000 STP600D
Pipe Temperature Sensor STP600D
112
Drayton
