Living Space
Temperature Sensors
STR100, 200 & 500 Series
We offer a wide range of temperature sensors for Living Space, Duct, Pipe and
Outdoor Applications. The range has been designed for ease of installation,
pleasing aesthetics, and full compatibility with The various Schneider Electric
Systems.
STR100 Series
The STR range of wall modules are designed to provide temperature sensing in a wide
variety of Living Space Applications. Contemporary design ensures they are suitable
for installation in both new and existing buildings. The STR wall modules are designed
to be mounted directly onto the wall or a back box/Jbox. The base plate is designed to
be compatible with a wide range of global fixing methods.
TAC Xenta 102-B/102-EF/102-VF/102-ES/103-A/104-A/110-D/121-FC
121-HP/280 / 300 / 401 / 700
Part
number
Model
number
Com Temp Sensor
Mode
Indicator
Xenta OP
Jack
Setpoint
Offset
Bypass
Button
Fan Speed
Control
004600100 STR100
I/O
1.8kΩ
004600110 STR100-W I/O
1.8kΩ
004600200 STR101
I/O
1.8kΩ
X
X
004600300 STR102
I/O
1.8kΩ
X
X
X
004600700 STR103
I/O
1.8kΩ
X
X
X
004600400 STR104
I/O
1.8kΩ
X
X
X
X
004600500 STR106
I/O
1.8kΩ
X
X
X
X
A-0-I-II-III
004600800 STR1
0
6-B
I/O
1.8kΩ
X
X
X
X
(no-icon)
A-0-I-II-III
004600900 STR106-3
I/O
1.8kΩ
X
X
x
(max 3°C)
X
A-0-I-II-III
004600600 STR107
I/O
1.8kΩ
X
X
X
X
Auto-off-On
TAC Xenta 102-AX and I/NET
Part
number
Model
number
Com Temp sensor
Mode
indicator
Xenta OP
Jack
Setpoint
offset
Bypass
button
Fan speed
control
004603000 STR200
I/O
10kΩ
004603010 STR200-W I/O
10kΩ
004603200 STR202
I/O
10kΩ
X
X
X
TAC Xenta 102-AX and I/NET
Part
number
Model
number
Com Temp sensor
Mode
indicator
Rj-10 Jack
Setpoint
offset
Bypass
button
Fan speed
control
004606000 STR500
I/O
10kΩ
004606100 STR502
I/O
10kΩ
X
X
X
004603200 STR504
I/O
10kΩ
X
X
X
X
STR200 Series
STR500 Series
