Pressure
Transmitters
SPP110
Pressure Transmitter
Part number Model number
Description
004702020
SPP110-100kPa
Wet Media Pressure
Transmitter
SPP110-100kPa
004702040
SPP110-250kPa
Wet Media Pressure
Transmitter SPP110-250kPa
004702060
SPP110-600kPa
Wet Media Pressure
Transmitter
SPP110-600kPa
004702080
SPP110-1000kPa
Wet Media Pressure
Transmitter
SPP110-1000kPa
004702100
SPP110-1600kPa
Wet Media Pressure
Transmitter
SPP110-1600kPa
004702120
SPP110-2500kPa
Wet Media Pressure
Transmitter
SPP110-2500kPa
004702140
SPP110-4000kPa
Wet Media Pressure
Transmitter
SPP110-4000kPa
SPP110
SPP110 pressure transmitters are intended for use in HVAC pipe systems to monitor
pressure. The SPP110 is an electronic pressure transmitter that converts the
measured pressure into an electric 0-10 V signal. The SPP110 is delivered with
2m (6.6 ft) cable and a G1/2 adapter nut.
Medium: any medium suitable for stainless steel.
Specifications
Output
0-10 V
Ranges
0-100 kPa, 0-250 kPa,
0-600 kPa, 0-1000 kPa,
0-1600 kPa, 0-2500 kPa,
0-4000 kPa ranges
Accuracy
Total of linearity, hysteresis and
repeatability
±0.5 % FS
Zero point residual voltage
< 50 mV
Supply
24 Vac / 15-36Vdc
