Pressure
Transmitters
SPW100 Series
Wet Differential
Pressure Transmitter
Part number Model number Description
6552047000 SPW100
Differential Water
Pressure Transmitter 0….0.5bar
6552048000
SPW102
Differential Water
Pressure Transmitter 0….1bar
6552049000 SPW104
Differential Water
Pressure Transmitter 0….1.6bar
6552050000 SPW106
Differential Water
Pressure Transmitter 0….2.5bar
6552051000 SPW108
Differential Water
Pressure Transmitter 0….4bar
6552052000 SPW110
Differential Water
Pressure Transmitter 0….6bar
6552053000 SPW112
Differential Water
Pressure Transmitter 0….10bar
6552054000 SPW114
Differential Water
Pressure Transmitter 0….16bar
SPW100
SPW Differential Wet Pressure Sensors utilise well proven ceramic technology.
They have a low sensitivity to change in temperature and a high resistance to
extreme temperatures.
Specifications
Output
3 wire 0 -10V
Ranges
0-0.5, 0-1.0, 0-1.6, 0-2.5, 0-4.0, 0-6.0,
0-10 and 0-16.0. All figures shown are
in bar.
Accuracy
Max. ±1% (varies depending on model)
Total of linearity, hysteresis and
repeatability
±1.25% Max.
Medium
Liquids and neutral gases
Supply
18…33VDC or 24VAC ±15%
Mounting bracket
Screws and female connector
providing IP65 when installed
are all included
