Pressure
Transmitters
SPD310/SPD360
Air Differential
Pressure Transmitters
Part
number
Model
number
Description
004700320 SPD310-100/300/500/1000Pa
Differential Air Pressure
Transmitters
SPD310-100/300/500/1000Pa
004700340 SPD310-1000/1200/2500/5000Pa
Differential Air Pressure
Transmitters
SPD310-1000/1200/2500/5000Pa
004700360 SPD360-300/500/1000/2500Pa
Differential Air Pressure
Transmitters
SPD360-300/500/1000/2500Pa
SPD310 / SPD360
SPD310 / SPD360 differential pressure transmitters are intended for use in air
handling systems for the monitoring of air ducts, filters and fans. SPD310 / SPD360
are electronic differential pressure transmitters that convert the differential pressure
measured into an electric 0-10 V signal. SPD360 has an LCD display, showing the
differential pressure in Pa.
SPD310 / SPD360 are delivered with a 2 metre tube and two plastic duct connectors.
Specifications
Output
0-10 V
Ranges
0-100 Pa, 0-300 Pa, 0-500 Pa, 0-1000 Pa,
0-1200 Pa, 0-2500 Pa, 0-5000 Pa
Accuracy
Linear output
0-100Pa
≤ 0.75%FS
≤ 1.5%
Linearity inc. temperature and hysterisis
0-100Pa
≤ 2%FS
≤ 4%FS
Accuracy at ambient temperature
of 25°C/UG-24V
≤ ±0.4%FS
