SCP110/SCC110
These devices are suitable for fixing to chilled pipework to sense and therefore
take control action against the formation of condensation.
The SCP110 is designed for direct mounting onto pipe systems. The sensor
element is mounted in the contact material below the housing.
The SCC110 has a remote sensor with a 2m wire. The sensor element is fitted
into a sensor head made of aluminium.
Part number
Model number
Description
006902500
SCP110
Pipe Condensation
Transmitter SCP110
006902510
SCC110
Contact Condensation
Transmitter SCC110
Condensation
Transmitter
SCP110/SCC110
Pipe, Contact
Condensation Transmitter
Specifications
Output
Relay contact (change-over),
24V/1A, potential-free,
contact material Ag/Ni 90/10
Range
Switching threshold adjustable 90 to
96%rH. Mid-position equals 93% rH
Supply
24Vac+/-10% / 18-32Vdc
