39
CAT-SENSORS-EU.BU.N.EN.2.2012.0.01.CC
Pressure
Transmitters
SPP930
Relative Pressure Switches
SPP930
SPP930 Pressure Switches are suitable for the monitoring of both liquid and gases
in HVAC, industrial equipment, manufacturing applications and process technology.
They cover the range from 120 to 6000 mbar and provide a high margin for over
pressure. They may be used in locations that experience high vibrations. The
product is supplied with a cover (not shown).
Specifications
Nominal voltage
250Vac
Nominal current
1A resistive loading
Nominal current
0.5A inductive loading
Current rating
0.1A resistive, 1A inductive
SPDT Dry Contacts
Service Life Mechanically 106 Switching Cycles
Electrical Connection Screw Terminal
Cable Gland PG11
Part number Model number
Description
004701160
SPP930-2200
Overpressure switch -
120 to 2200 mbar
044701170
SPP930-6000
Overpressure switch -
1000 to 6000 mbar
Note that this is a Huba relative pressure switch Type 625, class three product and
technical support will be provided by Huba. Click link
