Globe Valve Actuators
Forta Actuators
Force
Modulating control
Running time / stroke
Avg. power
consumption
Transformer
sizing
Part number
Description
N
9-25 mm
25-32 mm 32-51 mm VA
880-0210-030 M310
300
15s
20s
---
6
30
880-0211-030 M310 S2
300
15s
20s
---
6
30
880-0230-030 M400
400
60s
60s
---
7
30
880-0231-030 M400 S2
400
60s
60s
---
7
30
880-0310-030 M800
800
15s
20s
30s
10
50
880-0311-030 M800 S2
800
15s
20s
30s
10
50
880-0450-000 M1500
1500
15s
20s
30s
15
50
880-0451-000 M1500 S2
1500
15s
20s
30s
15
50
880-0500-000 M3000
3000
14-40s
40-50s
50-80s
25
50
880-0510-000 M3000 S2
3000
14-40s
40-50s
50-80s
25
50
S2 – 2 x SPDT Auxiliary end point switches, 24V AC, 4A AC-1
Forta Accessories
Part number
Description
880-0104-000
S2 – 2 x SPDT Axillary End Point Switches (24Vac 4A AC-1) (1)
880-0108-000
Stem heater Forta-Venta (1) – for media temp 0°C to -20°C
880-0109-000
Forta Yoke Heater for amb. temp -10°C, media temp -8°C
(1) Note: Not for Forta M700
Forta Linkage Kits for other valves
Part number
Description
880-0124-000
Linkage Forta-Satchwell L2SV
880-0116-000
Linkage Forta-Honeywell M6 and 1/4” stem
880-0118-000
Linkage Forta-Siemens
880-0125-000
Linkage Forta-Danfoss
880-0129-000
Linkage Forta-Spirax Sarco (M30:KE, KF, and KL; DN 15-100) [ AG52 ]
880-0127-000
AG50 linkage – Controlli flanged Valves with M40 threaded bonnet,
installed pre July 2009 types: VSG, VMB16, VBG (up to DN65).
880-0128-000
AG51 Linkage – Controlli Flanged Valves with M40 threaded bonnet, installed Pre July 2009 types:
VBG, SS, DS, VSS, VBA, 3V, VMS (all sizes) types: VSG, VMB16, (DN80 or larger), SSGA
880-0129-000
AG52 linkage – Controlli Threaded valves, types: VSB, VMB, VSB_F, VMB_F
880-0252-000
Linkage DN15-V298
880-0253-000
Linkage DN15-V2XX/V3XX
AV-811
Forta to VB-7000 valves (Siebe/TAC)
AV-812
Forta to VB-8000 valves (siebe / TAC)
880-0130-000
V321 DN65-100 to Forta (convert from M16 actuator)
