Air Quality
Transmitters
Living Space CO
2
Sensors
with Humidity Option
SCR Series
The all new SCR range of CO
2
transmitters now combine the option of adding a
humidity transmitter into a single unit. Temperature sensing for all current platforms
is available dependent on the model selected thus offering lower cost installation.
Outputs are user selectable, 0 to 10V, 0 to 5V or 4 to 20mA.
The sensor is auto calibrating using the Auto Baseline Calibration (ABC) feature and
will sense CO
2
concentrations in the range 0 to 2000ppm with an accuracy of ±2% of
measured value (at 20deg C and 101.3kPa).
The transmitter also include a relay that will switch at 800/1000 or1200ppm
dependent on internal switch settings.
Replacement humidity tips are available including a 2% NIST certificated tip.
If calibration is required, order the standard product and the replacement 2% tip.
Specifications
Input voltage
24VAC, 20 to 36VDC
Analogue output
4 to 20mA, 0 to 5V or 0 to 10V
Current draw
50 to 170mA
(dependent on input voltage)
Available products
Part
number
Model
number
Wall mounted C02 sensor with:
LED TEMP 2% RH System
5152400000 SCR110
x
x
TAC Vista 1.8K
5152402000 SCR110-H
x
x
x
TAC Vista 1.8K
5152420000 SCR110B
x
TAC Vista 1.8K
5152422000 SCR110B-H
x
x
TAC Vista 1.8K
5152404000 SCR210
x
x
TAC i/NET 10K T2
5152406000 SCR210-H
x
x
x
TAC i/NET 10K T2
5152424000 SCR210B
x
TAC i/NET 10K T2
5152426000 SCR210B-H
x
x
TAC i/NET 10K T3
5152408000 SCR510
x
x
Andover Continuum 10K T3
5152410000 SCR510-H
x
x
x
Andover Continuum 10K T3
5152428000 SCR510B
x
Andover Continuum 10K T3
5152430000 SCR510B-H
x
x
Andover Continuum 10K T3
5152412000 SCR610
x
x
Satchwell 10K T3 Resistor/Shunt
5152414000 SCR610-H
x
x
x
Satchwell 10K T3 Resistor/Shunt
5152432000 SCR610B
x
Satchwell 10K T3 Resistor/Shunt
5152434000 SCR610B-H
x
x
Satchwell 10K T3 Resistor/Shunt
5152416000 SCR810
x
x
I/A 10K T3 w/Shunt
5152418000 SCR810-H
x
x
x
I/A 10K T3 w/Shunt
5152436000 SCR810B
x
I/A 10K T3 w/Shunt
5152438000 SCR810B-H
x
x
I/A 10K T3 w/Shunt
5152339010 HS2NX
Replaceable RH Element, 2% NIST
5152339000 HS2XX
Replaceable RH Element, 2%
