Schneider Electric
SE7000 Series room controllers
SEZ7260 Series ordering
SE7682S
| Wireless central manager -
Coming soon!
Wireless central manager
Part Number
Description
Communication
SE7682S5045W
Wireless central manager
Wireless
With wireless central managers customers benefit from simple yet flexible management of multiple equipment controllers from
one convenient location. Facility managers can now efficiently administer parameters for up to 60 room controllers with one
wireless central manager, saving both time and effort.
Communication options:
-B = BACnet
®
MS/TP
-W= Zigbee
®
wireless
Control Output Type:
-C = Floating or on/off digital control outputs
-F = Analogue 0 - 10 VDC control outputs
SEZ7260 45
SEZ7656 Series ordering
PIR options:
-50 =PIR ready but PIR cover not included
-55 = Factory assembled with PIR cover
PIR options:
-50 =PIR ready but PIR cover not included
-55 = Factory assembled with PIR cover
Communication options:
-B = BACnet
®
MS/TP
-W= Zigbee
®
wireless
Communication options:
-E = 2H / 2C IAQ applications
-F = 1H / 2C modulating heat applications
-H = 3H / 2C heat pump applications
-R = 2H / 2C roof top aplications
-W= 2H / 2C water source heat
pump applications
SEZ7656 45
Example:
SE7656E5045W
•
Zoning System Controller
•
2H / 2C IAQ application
•
PIR Ready
•
Zigbee
®
wireless communication
Example:
SEZ7260F5545B
•
Zoning System Controller
•
Analogue outputs
•
Factory assembled PIR cover
•
BACnet
®
MS/TP communication
Digital stand-alone and communicating room controllers
* Some part number configurations may not be available.
Please refer to the tables for available versions.
* Some part number configurations may not be available.
Please refer to the tables for available versions.
