Schneider Electric
SE7000 Series room controllers
SE7200
SE7300
SE7600
Agency approval
CE, C-Tick, UL
CE, C-Tick, UL
CE, C-Tick, UL
Weight
0.34 kg (0.75 lb)
0.34 kg (0.75 lb)
0.34 kg (0.75 lb)
Dimensions (H x W x D)
Non-PIR model
125mm x 87mm x 30mm
(4.92” x 3.41” x 1.16”)
125mm x 87mm x 30mm
(4.92” x 3.41” x 1.16”)
125mm x 87mm x 30mm
(4.92” x 3.41” x 1.16”)
PIR model
125mm x 87mm x 38mm
(4.92” x 3.41” x 1.47”)
125mm x 87mm x 38mm
(4.92” x 3.41” x 1.47”)
125mm x 87mm x 38mm
(4.92” x 3.41” x 1.47”)
Power supply
10-30 VAC (50/60Hz)
10-30 VAC (50/60Hz)
10-30 VAC (50/60Hz)
Outputs
Analogue
0-10 VDC
0-10 VDC
0-10 VDC
Triac
30 VAC, 1 Amp
30 VAC, 1 Amp
30 VAC, 1 Amp
Operating conditions
0° - 50°C (32° - 122°F)
0 - 95% RH (Non-condensing)
0° - 50°C (32° - 122°F)
0 - 95% RH (Non-condensing)
0° - 50°C (32° - 122°F)
0 - 95% RH (Non-condensing)
Temperature sensor type
10K Type 2
10K Type 2
10K Type 2
Temperature sensor accuracy
± 0.5 °C (± 0.9 °F) @ 21 °C (70 °F)
± 0.5 °C (± 0.9 °F) @ 21 °C (70 °F)
± 0.5 °C (± 0.9 °F) @ 21 °C (70 °F)
Humidity sensor type*
N/A
Single point calibrated bulk polymer type
sensor
Single point calibrated bulk polymer type
sensor
Humidity sensor read range*
N/A
10 - 90% RH (Non-condensing)
10 - 90% RH (Non-condensing)
Humidity sensor accuracy*
N/A
±5% @ 20 - 80% RH (Non-condensing)
±5% @ 20 - 80% RH (Non-condensing)
Dehumidification setpoint range*
N/A
30 to 95% RH
30 to 95% RH
Economiser accuracy*
N/A
N/A
±3% typical
Operating conditions
0°C to 50°C ( 32°F to 122°F )
0% to 95% R.H. non-condensing
Storage conditions
-30°C to 50°C ( -22°F to 122°F )
0% to 95% R.H. non-condensing
Dimensions
125mm x 87mm x 30mm (4.92” x 3.41” x 1.16”)
Approximate shipping weight
155 grams (0.34 lbs)
Enclosure material
ABS - FRI [WT1337V] UV stabilised
Specs
Remote sensor specs
* Available with selected models.
Accessories and specifications
