Schneider Electric
SE7000 Series room controllers
Commercial interface (local override)
Part Number
Description
PIR Cover
Communication
SE7300F5045-ECM
Stand-alone ECM fan coil controller No
Stand-alone (network ready)
SE7300F5045B-ECM
BACnet ECM fan coil controller
No
BACnet
SE7300F5045W-ECM
Wireless ECM fan coil controller
No
Wireless
SE7300F5545-ECM
Stand-alone ECM fan coil controller Yes
Stand-alone (network ready)
SE7300F5545B-ECM
BACnet ECM fan coil controller
Yes
BACnet
SE7300F5545W-ECM
Wireless ECM fan coil controller
Yes
Wireless
Hotel/lodging interface (°C/°F selection)
Part Number
Description
PIR Cover
Communication
SE7305F5045-ECM
Stand-alone ECM fan coil controller No
Stand-alone (network ready)
SE7305F5045B-ECM
BACnet ECM fan coil controller
No
BACnet
SE7305F5045W-ECM
Wireless ECM fan coil controller
No
Wireless
SE7305F5545-ECM
Stand-alone ECM fan coil controller Yes
Stand-alone (network ready)
SE7305F5545B-ECM
BACnet ECM fan coil controller
Yes
BACnet
SE7305F5545W-ECM
Wireless ECM fan coil controller
Yes
Wireless
SE7300-ECM
| ECM fan coil controllers -
Coming soon!
More and more engineers are commonly specifying fan coil units that function with electronically commutated motors, which
offer better energy efficiency and reduced operating costs. The SE7300 ECM fan coil controller allows you to capitalise on this
additional energy savings by optimising fan control sequences of electronically commutated motors. The controller is optimised
to offer full proportional operation versus the traditional three-speed tap operation. This wall-mounted controller features an
easy-to-read digital display and built-in commissioning and configuration utility, temperature sensor and optional humidity and
passive infrared occupancy sensor (PIR) cover.
SER7300 Series ordering
Humidity sensor and control:
-0 = No humidity sensor
-5 = Internal humidity sensor
PIR options:
-50 =PIR ready but PIR cover
not included
-55 = Factory assembled with
PIR cover
Communication options:
-B = BACnet
®
MS/TP
-W= Zigbee
®
wireless
- = Network ready
SER73
45 A
Example:
SER7305A5545B
•
Line Voltage Fan Coil controller
•
Internal Humidity Sensor
•
Hotel/Lodging application,°C/°F
•
Factory assembled with PIR cover
•
BACnet
®
MS/TP communciation
Control key function:
-0 = Override, for commercial applications
-5 = °C/°F, for hotels/lodging applications
Digital stand-alone and communicating room controllers
* Some part number configurations may not be available.
Please refer to the tables for available versions.
