Schneider Electric
SE7000 Series room controllers
SE7600 Series ordering
SE7600F
| Roof top controllers for modulating heat -
Coming soon!
Part Number
Description
Scheduling Heat/Cool Stages PIR Cover Communication
SE7600F5045
Stand-alone modulating heat
controller
No
1H (analogue)/2C No
Stand-alone (network ready)
SE7600F5045B
BACnet modulating heat
controller
No
1H (analogue)/2C No
BACnet
SE7600F5045W
Wireless modulating heat
controller
No
1H (analogue)/2C No
Wireless
SE7600F5545
Stand-alone modulating heat
controller
No
1H (analogue)/2C Yes
Stand-alone (network ready)
SE7600F5545B
BACnet modulating heat
controller
No
1H (analogue)/2C Yes
BACnet
SE7600F5545W
Wireless modulating heat
controller
No
1H (analogue)/2C Yes
Wireless
SE7652F5045
Stand-alone modulating heat
controller
Yes
1H (analogue)/2C No
Stand-alone (network ready)
SE7652F5045B
BACnet modulating heat
controller
Yes
1H (analogue)/2C No
BACnet
SE7652F5045W
Wireless modulating heat
controller
Yes
1H (analogue)/2C No
Wireless
SE7652F5545
Stand-alone modulating heat
controller
Yes
1H (analogue)/2C Yes
Stand-alone (network ready)
SE7652F5545B
BACnet modulating heat
controller
Yes
1H (analogue)/2C Yes
BACnet
SE7652F5545W
Wireless modulating heat
controller
Yes
1H (analogue)/2C Yes
Wireless
The new SE7600F roof top terminal equipment controller with modulating heat can make your building more comfortable while still
meeting the ventilation codes for minimum building fresh air requirements. The easy-to-install SE7600F includes modulating heat
functionality, which allows the addition of an extra supply air temperature control loop to better control and condition the supply air
levels for a more comfortable occupant environment.
Example:
SE7652H5045E
•
Roof Top Controller
•
No local scheduling or programming
•
2H / 2C Application
•
PIR Ready
•
Zigbee
®
wireless communication
Programmability:
-0 = No local scheduling/
non programmable
-5 = Local scheduling/
prorammable
Economiser / Humidity control:
-0 = No local scheduling / Non programmable
-2 = Local scheduling / Programmable
-5 = With economiser no local scheduling /
Non programmable
-6 = With economiser local scheduling / Programmable
-7 = With Humidification / Dehumidification control
PIR options:
-50 =PIR ready but PIR cover
not included
-55 = Factory assembled with
PIR cover
Compatibility:
-A = 1H / 1C roof top unit applications
-B = 2H / 2C roof top unit applications
-E = 2H / 2C IAQ applications
-F = 1H / 2C modulating heat applications
-H = 3H / 2C heat pump applications
-W= 2H / 2C water source heat pump applications
Communication options:
-B = BACnet
®
MS/TP
-E = Echelon
®
-W= Zigbee
®
wireless
- = Network ready
SE76
45
Digital stand-alone and communicating room controllers
* Some part number configurations may not be available.
Please refer to the tables for available versions.
