Schneider Electric
SE7000 Series room controllers
Wireless gateway
Platform
PowerPC 405EP 250 MHz processor
64MB SDRAM & 64 MB serial flash
128 KB static RAM
Battery Backup - 5 minutes typical - shutdown begins within 10 seconds
Real-time clock - 3 month backup max via battery
Operating system
QNX RTOS
IBM J9 JVM Java Virtual Machine
NiagaraAX
Communications
2 Ethernet Ports – 10/100 Mbps (RJ-45 Connectors)
1 RS 232 Port (9 pin D-shell connector)
1 RS 485 non isolated port (3 Screw connector on baseboard)
Environment
Operating temperature range: 0° to 50°C (32°F to 122°F)
Storage temperature range: 0° to 60°C (32°F to 140°F)
Relative humidity range: 5% to 95%, non-condensing
Agency listings
UL 916, C-UL listed to Canadian Standards Association
(CSA) C22.2 No. 205-M1983 “signal equipment”
CE, FCC part 15 Class A
C-tick (Australia)
Power supply
VWG-PS-DC 24 VAC to 15 VDC panel mounted power supply for VWG
VWG-PS-AC 120 VAC to 15 VDC power supply for VWG with cord
Chassis
Construction: Plastic, din rail or screw mount chassis, plastic cover
Cooling: Internal air convection
Dimensions: 160.4mm (6.313”) W x 122.4mm (4.820”) H (including connectors) x 61.9mm (2.438”) D
Wireless accessories and specifications
Wireless specs
