TECHNICAL DETAILS
Accuracy from FS:
±1,5% (±3% for DPT±50 & DPT100)
(including: general accuracy, temperature drift,
linearity, hysteresis and repetition error)
Zero point calibration:
automatic with autozero element (-AZ)
Long term stability, typical 1 year:
• ± 1 Pa
Supply voltage:
24 VDC ±10 % / 24 VAC ±10 %
Power consumption:
< 1.0 W (<1.5W with Iout 20mA)
Output signals (3-wire):
• 0…10 VDC, Load R minimum 1K!
• 4…20 mA, maximum load 500!
Ambient temperature:
-10…+50 °C
Response Time:
0,8 / 4 s
Protection standard:
IP54
*R2 = number of measurement ranges per device, D = display,
AZ = autozero element
DPT-R2
Product code
Product description
Measuring range (Pa)
103.002.003
DPT100-R2-AZ
0…50 /100
103.002.005
DPT 100-R2-D-AZ
0…50 /100
103.003.003
DPT±100-R2-AZ
-50…+50 / -100…+100
103.003.005
DPT±100-R2-D-AZ
-50…+50 / -100…+100
103.004.003
DPT 250-R2-AZ
0…100 /250
103.004.005
DPT 250-R2-D-AZ
0…100 /250
2-range model for higher
accuracy in very low
measurement ranges
TECHNICAL DETAILS
Accuracy from FS:
±0,7% (±1,5% for DPT100)
(including: general accuracy, temperature drift,
hysteresis and repetition error)
Long term stability, typical 1 year:
• ± 1 Pa
Zero point calibration:
automatic with autozero element (-AZ)
Span point calibration:
with trimmer (see picture below)
Supply voltage:
24 VDC ±10 % / 24 VAC ±10 %
Power consumption:
< 1.0 W (<1.5W with Iout 20mA)
Output signals (3-wire):
• 0…10 VDC, Load R minimum 1K!
• 4…20 mA, maximum load 500!
Ambient temperature:
-10…+50 °C
Response Time:
0,8 / 4 s
Protection standard:
IP54
Reach the best accuracy!
Use a transmitter with
span point calibration.
DPT-SPAN
Product code
Product description
Measuring range (Pa)
103.002.019
DPT SPAN 100-AZ
0…50 /100
103.002.020
DPT SPAN 100-D-AZ
0…50 /100
103.003.023
DPT SPAN ±100-AZ
-50…+50 / -100…+100
103.003.024
DPT SPAN ±100-D-AZ -50…+50 / -100…+100
103.005.012
DPT SPAN 500-AZ
0…250 /500
103.005.013
DPT SPAN 500-D-AZ
0…250 /500
100 pa
0
10 V
