15
DPT-2W
Product code
Product description*
104.007.005
DPT-2W-2500-R8
x x x x x x x x
104.007.006
DPT-2W-2500-R8-D
x x x x x x x x
104.007.007
DPT-2W-2500-R8-Q
x x x x x x x x
104.007.008
DPT-2W-2500-R8-D-Q
x x x x x x x x
*R8 = number of measurement ranges per device, D = display, AZ = autozero element
Selectable measurement range
-100…+100 Pa
0…100 Pa
0…250 Pa
0…500 Pa
0…1000 Pa
0…1500 Pa
0…2000 Pa
0…2500 Pa
0…3000 Pa
0…4000 Pa
0…5000 Pa
0…7000 Pa
TECHNICAL DETAILS
Accuracy from FS:
±1,5% or (±6Pa <250 Pa)
(including: general accuracy, temperature drift, linearity, hysteresis
and repetition error)
Long term stability, typical 1 year:
see table below
Zero point calibration:
with push button
Supply voltage:
10…35 VDC
Max. supply current:
32 mA
Output signal:
4…20 mA
Max output current:
32 mA
Ambient temperature:
-10…+50 °C
Response Time:
0.8 / 4 s
Protection standard:
IP54
ACCESSORIES
SEE PAGE 50
Dimensions
!
"
#
!
$
!
"
#
$
%
$
#
&
%
&
#
&
'
(
#
&
!
!
#
&
$
'
#
&
)
)
)
)
*
#
'
+
+
